Create Sql Server Connection

This action creates a connection for SQL Server, and is intented for dynamically connecting to different servers and databases based on parameters or conditions during the execution of a Flow.

A 'Dynamic Connection' will override the 'Connection' on flow execution.

If you store the credentials for the SQL Server outside Flow (for example in your own Azure SQL or PostgreSQL database), use this action to dynamically create a connection. The connection returned from the action must then be used as the input to the Dynamic connection property of other SQL Server actions.

Connection details

Connection type

A connection type (or authentication type) must be selected before entering other properties.

SQL Server Authentication - default, sql server user name and password
MS Entra Password - Authenticate with a Microsoft Entra identity's username and password
Ms Entra Service Principal - Authenticate with a Microsoft Entra service principal, using its client ID and secret
User Connection String - user provids his own connection string

Properties for SQL Server and Microsoft Entra Password authentication

Name	Type	Description
Server name	Required	The name of the SQL Server. This can be the server name, IP address, or a named instance.
Database name	Required	Defines the specific database on the SQL Server to which the connection is made.
Username	Required	The username (or Entra Id/e-mail) used to authenticate the connection.
Password	Required	The password associated with the User to authenticate the connection.

Properties for Microsoft Entra Service Principal authentication

Name	Type	Description
Server name	Required	The name of the SQL Server. This can be the server name, IP address, or a named instance.
Database name	Required	Defines the specific database on the SQL Server to which the connection is made.
Client Id	Required	The Client ID of the Azure AD service principal (also known as an app registration).
Client secret	Required	The client secret (application secret) associated with the service principal in Azure AD.

User Connection String
